Heavy duty design with robust construction made for tough industrial application.
Wide passage closed impeller to handle light slurry and dirty water.
Easy operation and low maintenance design.
Back pull out design eases maintenance without disturbing mounted pipelines
Thick cross section of the wetted end parts brings long operation lifespan.
Choices of merchanical seal (stand) or gland packing sealing option to choose from.
Suitable high volume, medium pressure pump application. Capable to pump corrosive, clean or dirty water, and light slurry.
Flanges - Mounting PCD to fit ISO standard.
Mechanical Seal - Stainless steel metallic component with Carbon vs Ceramic sealing faces.
Bearings - Two (2) sealed for Life Heavy Duty Deep Groove Ball Bearings
Drive - Suitable for Direct coupled or vee pulley belt drive
4 pedestal sizes
Solid handling capacity — up to 70mmB
NBR
Around 85 deg'C (for higher temp aplications, please consult agent/dealer.)
